SM ER 5356

DETAILS

Features/Characteristics

SM ER 5356 wire typical applications include boats, ships, bicycles, trucks, pressure vessels, and automotive parts and equipment. This filler metal has one important limitation, which is its unsuitability at service temperatures exceeding 150°F (65 °C). This is due to the formation of Al2Mg at elevated temperatures at the grain boundaries, which makes the alloys prone to stress corrosion. This restricts its use when post-weld artificial aging. After anodizing, the colour typically appears white. ER5356 has nominal composition (wt-%) of 5 Mg balance Al. This filler metals is a non-heat-treatable wire used to weld the 5xxx series base metals to themselves and other alloys. It has become the most commonly used of all filler alloys because of its compatibility with most base alloys, its good strength, and its good feed ability when used as a GMAW electrode wire.

Mechanical properties of SM ER5356

Ultimate Tensile Strength        : 240 MPa

Welding Positions

All Position

Disclaimers

Service Information

Documentation

• Safety Data Sheet
• Certificates of Conformance

More Aluminium Alloy Filler Metal

CONFORMANCE/CLASSIFICATION

SM ER5183 WELD METAL CHEMISTRY (%)

SM ER5183 Aluminium Welding Wire Uses/Applications

1. Can be used to weld the Base materials (ASTM) 3004, 5052, 5083, 5086, 5154, 5454, 6005, 6061 aluminium alloys.
2. SM ER5356 is a 5% magnesium, all position, non-heat treatable wire used to weld the 5xxx series alloys with some common welding applications.
3. It is also used in the welding of aluminium, silicon, magnesium, aluminium, zinc and magnesium alloy and the repair welding of aluminium and magnesium alloy castings.
4. It is also used in boats, ships, bicycles, trucks, pressure vessels, and equipment.

TYPICAL OPERATING PROCEDURES/WELDING CURRENT (AC for GTAW) (DCEP for GMAW)
