Features/Characteristics
SME E11 is an electrode for low heat input welding of Nickel and suitable for Corrosion resistance against seawater, heat & good creep-resistance at high temperature. The weld metal is free from porosity and resistant to many chemicals. Suitable for applications with working temperatures from 196 °C to +450 °C. Protection of the reverse side is necessary when welding root runs.
SME E11 Welding Rod Uses/Applications
- Pump impellers, tubes.
- Welding of Monel and Monel-clad steels. Joining Monel to steel.
- Chemical Industry, Oil Industry, Shipbuilding Industry.
- Distillation tower, tanks.
Disclaimers
Service Information
Documentation
- Safety Data Sheet
- Certificates of Conformance
More Nickel and Nickel Alloys
Related products
MECHANICAL PROPERTIES
Ultimate Tensile Strength: 48 – 53 kgf/mm²
Elongation: 30 – 40%
TYPICAL OPERATING PROCEDURES (WELDING CURRENT)
|
Diameter
|
Current (Amps)
|
|---|---|
| 2.5 mm |
60 – 80
|
|
3.2 mm
|
90 – 120
|
|
4.0 mm
|
110 – 140
|
Availability
Standard Size: 4.0, 3.2, and 2.5 in 350 mm length.
Packing: 2,5 kg.
