DETAILS
Features/Characteristics
SME E 24 weld deposit is resistant to seawater corrosion, wide variety of acids and alkalis. It has High temperature strength and oxidation stability and High resistance to pitting, crevice, inter-crystalline and stress corrosion cracking.
SME E24 Welding Rod Uses/Applications
- Deposits are similar to ENiCrMo-3.
- To join and hard-surfacing of identical or similar grades of heat-resisting steels and alloys.
- Welding alloy steels like H 11, H 13, 17 Mn 4, St E 355, 15 Mo 3.
- Suitable in seawater and offshore plants, chemical-engineering (nitric, hydrochloric, sulphuric, phosphorous acid as well as alkalis), flue gas dust collectors.
Disclaimers
Service Information
Documentation
- Safety Data Sheet
- Certificates of Conformance
More Nickel and Nickel Alloys
Related products
MECHANICAL PROPERTIES
Yield Strength: 42-52 kgf/mm²
Ultimate Tensile Strength: 76-86 kgf/mm²
Elongation (L = 4d): 30-35%
Charpy V-Notch Impact Energy at 20°C: 55-80 J
Charpy V-Notch Impact Energy at 196°C: 50-60 J
ALLOY BASIS
Cr, Ni, Mo, Nb, Mn, Fe
TYPICAL OPERATING PROCEDURES (WELDING CURRENT) DC (+)
|
Diameter
|
Current (Amps)
|
|---|---|
| 2.5 mm |
45 – 70
|
|
3.2 mm
|
70 – 110
|
|
4.0 mm
|
100 – 140
|
Availability
Standard Size: 4.0, 3.2, and 2.5 in 350 mm length.
Packing: 2, 5 kg.
